用于样本规定的矿井配电场所,适用环境不含甲烷、煤尘等爆炸性危险。选型需核对容量、电压、湿度、海拔、倾斜和安装防护,不能将普通矿用型号直接用于有爆炸危险的区域。
Oil free, with strong fire resistance, eliminating the risk of oil leakage; Capable of withstanding short-circuit current and overvoltage, and adapting to harsh environments.
Using environmentally friendly materials, low noise and no pollution, to assist in the construction of a green power grid.
Efficient cooling system ensures that the equipment maintains low temperature during long-term operation, effectively extending the service life of the equipment.
Humanized design, simple operation, convenient and fast daily inspection and maintenance, significantly reducing operating costs.
Durable shell design, impact resistance, corrosion resistance, able to adapt to various complex and harsh working environments.
Modular structure design, supporting quick disassembly and assembly, combined with intelligent monitoring system, making operation and maintenance work more worry free and effortless.
10000V
| 额定容量 (kVA) Rated capacity | 空载电流 (%) No load current | 短路阻抗 (%) Short-circuit impedance | 空载损耗 (kW) No load losses | 负载损耗 (kW) On load losses |
| 50 | 2.5 | 4 | 0.35 | 0.68 |
| 100 | 2.5 | 0.5 | 1.05 | |
| 200 | 2 | 0.85 | 1.8 | |
| 315 | 1.8 | 1.2 | 2.5 | |
| 400 | 1.8 | 1.35 | 3 | |
| 500 | 1.5 | 1.6 | 3.5 | |
| 630 | 1.5 | 1.8 | 4.1 | |
| 800 | 1.2 | 2.1 | 5.1 | |
| 1000 | 1.2 | 4.5 | 2.35 | 6.1 |
| 1250 | 1 | 2.8 | 7.4 | |
| 1600 | 1 | 5 | 3.45 | 8.5 |
| 2000 | 0.7 | 4.05 | 9.7 | |
| 2500 | 0.7 | 5.5 | 4.7 | 10.8 |
| 3150 | 0.7 | 5.5 | 12.8 | |
| 4000 | 0.7 | 6 | 6.3 | 15 |
| 5000 | 0.6 | 7.3 | 17.6 | |
| 6300 | 0.6 | 8.5 | 20 |
6000V
| 额定容量 (kVA) Rated capacity | 空载电流 (%) No load current | 短路阻抗 (%) Short-circuit impedance | 空载损耗 (kW) No load losses | 负载损耗 (kW) On load losses |
| 50 | 2.5 | 4 | 0.31 | 0.55 |
| 100 | 2.5 | 0.47 | 0.92 | |
| 200 | 2 | 0.74 | 1.55 | |
| 315 | 1.8 | 0.99 | 2.15 | |
| 400 | 1.8 | 1.17 | 2.6 | |
| 500 | 1.5 | 1.35 | 3.1 | |
| 630 | 1.5 | 1.62 | 3.68 | |
| 800 | 1.0 | 1.85 | 4.5 | |
| 1000 | 1.0 | 2.1 | 5.4 | |
| 1250 | 1.0 | 2.48 | 6.5 | |
| 1600 | 0.8 | 3 | 8 | |
| 2000 | 0.6 | 4.5 | 3.4 | 9.5 |
| 2500 | 0.6 | 5 | 4.05 | 10.6 |
| 3150 | 0.6 | 5.5 | 4.75 | 12.5 |
| 4000 | 0.6 | 6 | 5.5 | 14 |
| 5000 | 0.5 | 6.4 | 15.8 | |
| 6300 | 0.5 | 7.6 | 18 |
